Equipment parameters: 1. Blank size: 1600x1600MM (length x width). 2. Spinning depth: within 300MM. 3. Spinning product thickness: within 2.5MM (iron plate) 4. Internal spinning diameter: 350-1400MM 5. Control mode: NC system 6. Drive mode: servo + hydraulic 7. Machine weight: 6.8 tons 8. Dimensions: 2.5mx2.1mx3.6m (outer dimensions) 9. Machine power: 29kw 10. Power type: 380v three-phase four-wire

SD1200-1 CNC spinning machine is derived from European technology and is manufactured by combining modern CNC technology and advanced processing and testing equipment. This spinning machine is a powerful model developed for spinning processing of high-strength and thick-walled parts. In production applications, the equipment has the characteristics of stability, no vibration, large feed volume and safe operation. The processed products have smoother surfaces and more uniform wall thickness. It can significantly reduce material waste, improve product dimensional accuracy, make arc transitions smoother and arcs more precise, and also significantly reduce workers’ workload and ensure employees’ operational safety.

1. Equipment introduction: 1. CNC spinning machine, manufactured by combining modern CNC technology and advanced processing and testing equipment. This spinning machine is designed for conventional products. It is precisely controlled digitally and uses the spinning forming process to produce workpieces of various sizes and shapes to meet the individual needs of customers. 2. The workpiece replacement process is simple. You only need to install a new mold, call the corresponding program, and perform accurate calibration to quickly put it into production. 3. This machine has undergone strict process flow and quality control to achieve a high degree of consistency in mass production, ensuring that every product meets high quality standards. 4. The equipment is easy to operate. It only needs one button to start and the workpiece can be loaded and unloaded manually. 5. In production applications, the surface of processed products is smooth and the wall thickness is more uniform. It can significantly reduce material waste, improve product dimensional accuracy, smooth arc transitions and precise arcs. It can also significantly reduce workers' labor and ensure employees' operational safety.

SD3000-2 CNC spinning machine is manufactured from European technology, combined with modern CNC technology and advanced processing and testing equipment. This spinning machine is a powerful model developed for spinning processing of high-strength, thick-walled parts. In production applications, the equipment has the characteristics of smoothness, no vibration, large feed capacity, and safe control. The processed product has a smooth surface and a more uniform wall thickness. It can significantly reduce material waste, improve product dimensional accuracy, smooth arc transitions and precise arcs. It can also significantly reduce workers' labor and ensure employees' operational safety. 2. Process principle Place the cut round slab on the center bracket, and use a hydraulic tail jack to press the slab against the end face of the mold. Multi-pass spinning is carried out through the spinning wheel, and the movement trajectory is controlled by the CNC system, which can realize the movement and differential compensation of various contours such as arcs, diagonals, straight lines, etc., to meet the contour requirements of various products. The contour movement of the product is controlled by CNC system programming, which is easy to apply and safe to operate.

Product Description: 1. With mature CAD drawing and programming software functions, the motion trajectory of the rotary wheel can be a straight line, an arc, a multi-arc connecting line, and a combined curve, etc., and can be input into the computer for standardized programming of the pass. 2. The operator can input the process parameters and spinning pass through the keyboard and operation panel, and can edit, store and call them at will. 3. It has the function of "copying" the core mold contour protection, that is, when the process is adjusted and the teaching is recorded back, the rotary wheel will not collide with the core mold. 4. The machine tool can pause the feed speed and spindle speed in the automatic program. It is equipped with travel limit protection, software and hardware limit protection in the control system, fault detection and alarm functions. 5. The machine automatically detects faults of each unit when it is turned on, and has functions such as automatic diagnosis and overload protection. 6. According to the user's requirements, various special shapes of parts can be spun to ensure that the relevant dimensions such as the workpiece surface, diameter, and thinning rate meet the requirements.

1. Maximum spinning sheet diameter: within 1200MM 2. Spinning length: within 800mm 3. Maximum spinning product thickness: within 4MM (stainless steel)

Technical requirements of CNC spinning machine: 1. Maximum spinning sheet diameter: within 1200MM 2. Spinning length: within 800mm Maximum spinning product thickness: within 10MM (stainless steel)

Technical requirements: 1. Maximum spinning sheet diameter: within 1200MM 2. Spinning length: within 500mm 3. Maximum spinning product thickness: within 4MM (carbon steel)

The three-wheel high-power spinning machine is mainly used for thinning or thickening the thickness of cylindrical parts and the spinning forming of some small-diameter thick plates. It can also be used for surface spinning hardening treatment of some workpieces. The equipment has the characteristics of high rigidity and high precision, and can process precision cylindrical parts, high-pressure gas cylinders, servo hydraulic cylinders, engine housings, etc. The 3 spinning wheels are arranged at 120 degrees, and the overall structure of the spinning wheel seat has a reasonable spinning force bearing capacity. The three wheels of the equipment can operate independently, and can also perform forward spinning, reverse spinning, staggered spinning (select configuration), etc. The spindle has an angle directional stop function, which is convenient for mold disassembly and assembly, and supports special forming processes. There are two ways of spindle center unloading and slide unloading. The equipment adopts the latest technology and standard components to ensure low use and maintenance costs under the condition of efficient production. CNC sheet metal forming machine, CNC flow forming machine, CNC 2-roll flow forming machine, CNC 3-roll flow forming machine, CNC metal spinning lathe machinery

SD-NX-1600 CNC internal spinning machine is specially designed for spinning the inner hole of the reinforced plate of the air inlet of air conditioning ventilator. The feature of this machine is that the plate is fixed and the spinning wheel works inside the plate. Multiple holes can be spun on the plate in a single operation. The equipment adopts CNC technology and can accurately handle complex curve spinning requirements such as straight edges and arc edges.

CNC spinning machine molds are simple, low-cost and stable in production, and are suitable for the production of small batches and multiple varieties of workpieces.

Gas Cylinder Shrinkage Spinning Machine is one kind of products of Dading.CNC Spinning Machine is China leading manufacturer of Dading,we are specialize in Dading.Please contact us if you need more information about Gas Cylinder Shrinkage Spinning Machine.
